Description
Specifications
AC or DC Output Voltage dc
Output Voltage 24V dc
Output Current 10A
Power Rating 240W
Electrical Phase 1
Type Switch Mode
Height 124mm
Width 38mm
Depth 117.8mm
Mounting Type DIN Rail Mount
Ripple And Noise 100mV Pk-Pk
Efficiency 93%
Maximum Temperature +70°C
Minimum Temperature -40°C
Hazardous Area Certification ATEX, IECEx
Series S8VK-S
Standards Met ANSI/ISA 12.12.01, ATEX: EN 60079-0 -15, CSA C22.2 No. 213, cUL: CSA C22.2 No. 107.1, cUR: CSA C22.2 No. 60950-1, EN 60950-1, EN/IEC 61558-2-16:2009+A1:2013, EN: EN 50178, IEC-EX: IEC 60079-0 -15, Lloyd’s Register DNV GL, PELV (EN/IEC 60204-1), UL Listed: UL 508, UL UR: UL 60950-1
Output Voltage Adjustment Range 21.6 → 28V
