Description
Attributes
Outer Diameter 108 mm (4.25 inch)
Thread Size M32 x 1.5
Length 223 mm (8.78 inch)
Gasket OD 102 mm (4.02 inch)
Gasket ID 92 mm (3.62 inch)
Efficiency 50% 20 micron
Efficiency Test Std JIS D 1611
Bypass Valve Yes
Bypass Valve Setting LR 1.7 bar (25 psi)
Bypass Valve Setting HR 2.1 bar (30 psi)
Media Type Cellulose
Collapse Burst 6.9 bar (100 psi)
Type Combination
Style Spin-On
Primary Application CATERPILLAR 5I7950
